15 Degree Angled Offset Receiver
| Origin |
USA |
|---|
Category: (9021) Orthopedic Devices and Prosthetics
Tags: EZ Adapt Series, Medical, Modular Components, Prosthetics
Brand: ST&G
Description
EZ ADAPT SERIES
EZ Adapt components provide versatility to shift and/or rotate as needed, offering easy solutions to prosthetic alignment without adding significant weight or requiring socket modification.
-
Warranty: 2 years
1713T – 15º Angled Offset Receiver
-
Description: Provides 15 degrees of angulation and 12.6 mm of offset. This lightweight, space-saving device also includes the added benefit of rotation.
-
Material: Titanium
-
Product Weight: [Not specified]
-
Weight Limit: 136 kg / 300 lbs
Technical Data
Torque Values
| Connection Type | Torque (Nm) | Hex (mm) |
|---|---|---|
| M8 Set Screw | 15 Nm | 4 mm wrench |
| M6 Cap Screw | 10 Nm | 5 mm wrench |
